1500W 2000W 3000W Laser Cleaning Machine With 300mm 650mm Beam
1500W 2000W laser rust cleaning machine to clean laser rust remover
Machine features:
Laser source: MAX, Raycus or BWT, IPG;
Laser power: 1000W-3000W;
Voltage: 220V, 1 phase; 380V/3 phase, 50/60HZ
Scanning width: 650±10mm;
Cleaning efficiency: 15-45m2/h;
Ambient humidity: ≤70% without condensation;
Total power: 6000-10000W (including chiller);
Cooling method: water cooling;
Laser wavelength: 1080±1nm;
Cooling water requirements: pure water or distilled water.
Non-contact cleaning, no consumables, no damage, no chemical pollution, the laser cleaning machine can clean resin, oil, dirt, rust, coating, paint on the surface of the object.
Upgraded version of laser cleaning head - self-developed, light and easy to use. 800mm focal length, cleaning width up to 300mm, also up to 650mm
Suitable for a variety of scenarios - mold cleaning, paint stripping or coating removal, pretreatment of parts before painting, cleaning of aerospace parts, pretreatment of oxide removal before welding, etc.
Laser 2-year warranty, lifetime technical support
UPS/FedEx shipping to door about 10 to 15 days.
Specification
| MODEL NO. | Fiber Laser Cleaning Machine |
| Fiber Power | 1000W 1500W 2000W |
| Cooling Mode | Water Cooling and Protection System |
| Laser Wave Length: | 1064nm |
| Laser Type | Fiber |
| Cleaning Width | 0-300mm/650MM |
| Gross Power | 3-7KW |
| Cleaning preview | Red light |
| Laser Power adjust range | 10-100 % |
| Operating Temperature | 0-45° |
| Operating Humidity: | 5-95% |
CW laser cleaning machine with the lastest laser gun
This laser gun
1. maximum support 650mm(2-3 times compare to others) laser beam width, could high reduce the cleaning time
2. it could continuous working 72 hours even in 3000w, very stable quality
3. Have many type cleaning model, such as straight line, circle, square etc. to meet the needs of different cleaning pieces.
4. More important is it have triple security protection, to make sure operating safety.
Super power cleaning Gun
| Power supply (V) | 220V ± 10% AC 50/60Hz |
| Placement environment | Flat, vibration and shock free |
| Working Environment (℃) | 10 ~ 40 |
| Working environment humidity (%)＜70 |
| Cooling method | Water chiller cooling |
| Suitable Wavelength | 1064 (±10nm) |
| Suitable laser power | ≤ 3000w |
| Reflector | 20*15.2 T1.6 |
| Maximum supported air pressure | 15 bar |
| Focus vertical adjustment range | ± 10mm |
| Spot adjustment range | Line 0~300mm |
| Net Weight | 0.7kg |
How laser to do cleaning work?
1) Powerful, short-pulse, and fast-moving laser pulses act on the target surface to generate tiny plasma ruptures, shock waves, thermal stress, etc., which sublime and evaporate surface materials.
2) The focused laser beam can accurately evaporate surface objects or dirt.
3) Fiber laser cleaning is suitable for metal surfaces. The processed and optimized laser beam will not change the metal properties or damage the laser-treated surfaces. The precisely tuned laser beam only acts on the coating, residue or oxide, and will not harm the underlying surface of the base material.
4) By adjusting other parameters, the laser beam can accurately and easily achieve the required cleaning effect.
Machine parameters
| Model | RL-C1000 | RL-C1500 | RL-C2000 |
| Wavelength | 1080nm | 1080nm | 1080nm |
| Average power | 1000W | 1500W | 2000W |
| Frequency | 20-50 kHz | 50 kHz | 50 kHz |
| Laser type | CW fiber laser | CW fiber laser | CW fiber laser |
| Clean speed | ≤40 M²/Hour | ≤40 M²/Hour | ≤40 M²/Hour |
| Fiber cable length | 10M(others for optional) | 10M(others for optional) | 10M(others for optional) |
| Working life | 100,000 hours | 100,000 hours | 100,000 hours |
| Machine weight | 120kg | 120kg | 120kg |
| Cooling | Water chiller cooling | Water chiller cooling | Water chiller cooling |
| Optional | Manual/Auto | Manual/Auto | Manual/Auto |
| Temperature | 5-40℃ | 5-40℃ | 5-40℃ |
| Beam width | 10-70mm | 10-70mm | 10-70mm |
| Clean speed | Single Phase
220V,50/60HZ | Single Phase
220V,50/60HZ | Single Phase
220V,50/60HZ |
Cleaning samples
